| Operation Form | Handle |
| Wiper | Single Wiper |
| Brake Form | Three Wheel Disc Brake |
| Material of Body | Iron |
| Motor Type | 1500W Permanent magnet / Synchronous |
| Controller Type | 1500W Permanent magnet / Synchronous |
| Rear Axle | Integrated Arms |
| Dash | Luxury MP5 Dash |
| Multimedia | USB, SD, Radio |
| Hub | Iron (12inch * 2.5) |
| Tire | 400-12 |
| Reversing Image | Standard |
| Cover Cloth | Cage Structure |
| Battery | 120AH Dry Battery |
| Charger | Vehicle Mounted |
| Size (mm) | 2600 * 1250 * 1750 |
| Minimum Ground Clearance (mm) | 150 |
| Minimum turning Radius (m) | 4 |
| Wheel Base (mm) | 1850 |
| Wheel Track (mm) | 1350 |
| Row Number | 2 |
| Passenger Number | 4 |
| Kerb weight (kg) | 280 (except battery) |
| Maximum Bearing Capacity (kg) | 300 |
| Charging Time (h) | 6-8 |
| Max Speed (km/h) | 30 |
| Braking Length (m) | 8 |
| Cruising Mileage (km) | 120 |
The vehicle is equipped with a 1500W permanent magnet/synchronous motor and a matching 1500W permanent magnet/synchronous controller for efficient performance.
The vehicle has 2 rows and can accommodate up to 4 passengers. Its overall dimensions are 2600mm in length, 1250mm in width, and 1750mm in height.
It features a 120AH dry battery with a vehicle-mounted charger. The standard charging time is between 6 to 8 hours.
The vehicle has a maximum speed of 30 km/h and offers a cruising mileage range of up to 120 km.
The vehicle is designed with a three-wheel disc brake system, has a braking length of 8 meters, and comes equipped with a standard reversing image system for safer driving.
The body is made of iron with a cage structure cover cloth, and it is fitted with iron hubs (12inch*2.5) and 400-12 tires.
