| Size (mm) | 1470*450*1006 | Battery Type | Lead-acid Battery |
| Weight (without battery) (kg) | 35 | Electric Range | 40/60 km |
| Loaded Mass (kg) | 100 | Max Speed (km/h) | 40 |
| Climbing Degree (°) | 25 | Standard Configurations |
|
| Body Frame Material | Q195 Iron | Tire | 20*2.15 |
| Brake | Drum |
Customization Available: All models can be customized according to the user's needs, scenario changes, battery and motor specifications, as well as modifications to range and maximum speed.
| Version | Standard | Advanced | Premier |
|---|---|---|---|
| Battery | 60v 20ah | 72v 20ah | 72v 35ah |
| Motor Power | 800-1000w | 1200-1500w | 1500-2000w |
| Endurance | 50km | 60km | 70km |
| Maximum Speed | 45km/h | 55km/h | 65km/h |
Tailor-made assembly solutions designed to meet the demands of different global markets and customer requirements.
We support customers in building their own assembly lines and enhancing self-assembly capacity and output efficiency through dedicated guidance.
Comprehensive and professional technical support to resolve any queries and operational challenges during the assembly process.
Specialized training programs designed to quickly familiarize your workforce with assembly techniques, minimizing errors and optimizing productivity.
Sharing industry-leading practices and technical innovations to enhance production methodologies and market competitiveness.
Can the electric range and maximum speed be customized?
Yes, all models can be fully customized based on user requirements, including adaptations for specific usage scenarios, motor power adjustments, and battery size modifications to vary the overall range and speed.
What type of battery is used in these configurations?
The standard setup uses a reliable Lead-acid Battery. Depending on your choice of configuration (Standard, Advanced, or Premier), we offer options ranging from 60v 20ah to 72v 35ah.
What are the main configuration differences between the Standard, Advanced, and Premier versions?
The differences lie in battery capacity (60v 20ah to 72v 35ah), motor power (from 800-1000w up to 1500-2000w), endurance range (50km to 70km), and maximum speed limits (45km/h to 65km/h).
What components make up the standard suspension system?
Our standard configurations feature advanced shock absorption systems: the front wheel is fitted with Hydraulic Shock Absorption, while the rear wheel is equipped with a Straight Spring Shock Absorption system.
Do you offer complete CKD (Complete Knock Down) assembly support?
Yes, we provide comprehensive CKD assembly solutions and technical training to empower clients to construct their own assembly lines, optimize self-assembly capacities, and improve operational output.
What are the dimensions and load capacities of the standard frame?
The standard dimensions are 1470*450*1006 mm, made of sturdy Q195 Iron, supporting a maximum loaded mass of 100 kg and up to a 25° climbing capability.
